Brass
MMC strengthens its commitment with the 45 yrs. experience of the owner in Indian Metal Market . We have all the regular sizes of Brass Rods / Flats in ready stock.
Copper & Copper Alloy (Brass) Rod, Section, Coil & Hollow |
||||||||
| Range of Products | ||||||||
| Rods | Dia |
1.5 mm to 200mm
|
||||||
| Bars | Square : A/F |
3mm to 100mm
|
||||||
| Hex : A/F |
3mm to 100mm
|
|||||||
| Flats/Strips | Thickness |
2mm to 50mm
|
||||||
| Width |
6mm to150mm
|
|||||||
| Sections | Circumscribed Dia |
90mm
|
||||||
| Coils | Dia |
1.5mm to 15mm
|
||||||
| Hollows | Bore |
10mm to Above
|
||||||
| Tubes | Wall Thickness |
0.5mm (25
SWG)
|
||||||
| Weight of Brass Rods in Kilo Grams per meter | ||
|
Round
Rods
|
 |
Weight per meter = (AxAx0.006676)kg. |
|
Square
Rods
|
 |
Weight per meter = (AxAx0.008500)kg. |
|
Rectangle
Rods/Strips
|
 |
Weight per meter = (AxBx0.008500)kg. |
|
Hex
Rods
|
 |
Weight per meter = (AxAx0.007361)kg. |
| NOTE : Weight of Copper Rods = 1.0517 x The Corresponding Weight of Brass Rod | ||
| 1 Meter=100 Cms=1000 mm=39.37 Inches=3.28 Feet | ||
We make all the qualities of extruded brass according to IS-BS specifications as per customers requirement
| Weight Brass Rods In Kilogram Per Linear Foot | ||||||||||||||||||||||||
| Diameter
(width across the flat) |
(Weight per feet in kgs.) | |||||||||||||||||||||||
| Size in inches |
Decimal in inches |
Rounds | Hexagonals | Rectangular | ||||||||||||||||||||
| 1/8 | .125 | .0205 | .0228 | .0260 | ||||||||||||||||||||
| 3/16 | .1875 | .0461 | .0511 | .0589 | ||||||||||||||||||||
| 1/4 | .25 | .0821 | .0908 | .1045 | ||||||||||||||||||||
| 5/16 | .3125 | .1287 | .1419 | .1638 | ||||||||||||||||||||
| 3/8 | .375 | .1848 | .224 | .2355 | ||||||||||||||||||||
| 7/16 | .4375 | .2519 | .2779 | .3208 | ||||||||||||||||||||
| 1/2 | .5 | .329 | .36 | .4189 | ||||||||||||||||||||
| 9/16 | .5625 | .4161 | .4609 | .5293 | ||||||||||||||||||||
| 5/8 | .625 | .5156 | .5658 | .6525 | ||||||||||||||||||||
| 11/16 | .6875 | .6206 | .6845 | .7894 | ||||||||||||||||||||
| 3/4 | .75 | .7392 | .8168 | .940 | ||||||||||||||||||||
| 13/16 | .8125 | .867 | .9582 | 1.1042 | ||||||||||||||||||||
| 7/8 | .875 | 1.0084 | 1.1088 | 1.2822 | ||||||||||||||||||||
| 15/16 | .9375 | 1.1544 | 1.2731 | 1.4738 | ||||||||||||||||||||
| 1 | 1.00 | 1.3141 | 1.451 | 1.6746 | ||||||||||||||||||||
| 1.1/8 | 1.125 | 1.6654 | 1.8343 | 2.1218 | ||||||||||||||||||||
| 1.1/4 | 1.25 | 2.0534 | 2.2678 | 2.6192 | ||||||||||||||||||||
| 1.3/8 | 1.375 | 2.4868 | 2.7424 | 3.1667 | ||||||||||||||||||||
| 1.1/2 | 1.5 | 2.9614 | 3.2625 | 3.769 | ||||||||||||||||||||
| 1.5/8 | 1.625 | 3.3424 | 3.8329 | 4.4261 | ||||||||||||||||||||
| 1.3/4 | 1.75 | 4.0291 | 4.4444 | 5.1288 | ||||||||||||||||||||
| 1.7/8 | 1.875 | 4.6269 | 5.1014 | 5.8908 | ||||||||||||||||||||
| 2 | 2.00 | 5.2657 | 5.8041 | 6.703 | ||||||||||||||||||||
| 2.1/4 | 2.25 | 6.662 | 7.3464 | 8.4826 | ||||||||||||||||||||
| 2.1/2 | 2.50 | 8.225 | 9.0667 | 10.4721 | ||||||||||||||||||||
| Conversion Table SWG To INCHES | ||||||||||||||||||||||||
| S.W.G No. |
Thickness | S.W.G No. |
Thickness | |||||||||||||||||||||
| In | mm |
In | mm | |||||||||||||||||||||
| 7/0 | .500 | 12.700 | 18 | .048 | 1.219 | |||||||||||||||||||
| 6/0 | .464 | 11.785 | 19 | .040 | 1.016 | |||||||||||||||||||
| 5/0 | .432 | 10.973 | 20 | .036 | .914 | |||||||||||||||||||
| 4/0 | .400 | 10.160 | 21 | .032 | .813 | |||||||||||||||||||
| 3/0 | .372 | 9.449 | 22 | .028 | .711 | |||||||||||||||||||
| 2/0 | .348 | 8.839 | 23 | .024 | .610 | |||||||||||||||||||
| 0 | .324 | 8.229 | 24 | .022 | .559 | |||||||||||||||||||
| 1 | .300 | 7.620 | 25 | .020 | .508 | |||||||||||||||||||
| 2 | .276 | 7.010 | 26 | .018 | .457 | |||||||||||||||||||
| 3 | .252 | 6.401 | 27 | .0164 | .417 | |||||||||||||||||||
| 4 | .232 | 5.894 | 28 | .0148 | .376 | |||||||||||||||||||
| 5 | .212 | 5.385 | 29 | .0136 | .345 | |||||||||||||||||||
| 6 | .192 | 4.877 | 30 | .0124 | .315 | |||||||||||||||||||
| 7 | .176 | 4.470 | 31 | .0116 | .295 | |||||||||||||||||||
| 8 | .160 | 4.064 | 32 | .0108 | .275 | |||||||||||||||||||
| 9 | .144 | 3.658 | 33 | .0100 | .254 | |||||||||||||||||||
| 10 | .128 | 3.251 | 34 | .0092 | .234 | |||||||||||||||||||
| 11 | .116 | 2.946 | 35 | .0084 | .213 | |||||||||||||||||||
| 12 | .104 | 2.642 | 36 | .0076 | .193 | |||||||||||||||||||
| 13 | .092 | 2.337 | 37 | .0068 | .173 | |||||||||||||||||||
| 14 | .080 | 2.032 | 38 | .0060 | .152 | |||||||||||||||||||
| 15 | .072 | 1.829 | 39 | .0052 | .132 | |||||||||||||||||||
| 16 | .064 | 1.626 | 40 | .0048 | .122 | |||||||||||||||||||
| 17 | .056 | 1.422 | ||||||||||||||||||||||
Specification Table Of Brass
|
MATERIAL
DESCRIPTION |
STANDARD
SPECIFICATIONS
|
COPPER |
LEAD
Pb% |
TIN
Sn% |
IRON
Fe% |
ALUMINIUM
Ai% |
MANGANESE
Mn% |
OTHER
ELEMENTS
|
ZINC
ZN% |
NICKLE
N% |
|
FREE
CUTTING BRASS TYPE I
|
IS
: 319/89
BSS : 249 EQUV. : BS 2874/86 CZ121Pb3 |
56
to 59
|
2.0
to 3.5
|
-
|
0.35
Max
|
-
|
-
|
0.7
Max
|
Remn.
|
-
|
|
FREE
CUTTING BRASS
TYPE II |
IS
: 319/89
EQUV.: BS 2874/86 CZ124 |
60
TO 63
|
2.5
to 3.7
|
-
|
0.35
Max
|
-
|
-
|
.05
Max
|
Remn.
|
-
|
|
FREE
CUTTING BRASS
TYPE III |
IS
: 319/89
BSS : 249 EQUV. : BS 2874/86 CZ124 |
60
TO 63
|
0.5
to 1.5
|
-
|
0.20
Max |
-
|
-
|
0.5
Max
|
Remn.
|
-
|
|
FORGING
BRASS
|
IS
: 3488/80
BSS : 218 EQUV. : BS 2874/86 CZ122 CuZn42Pb2 |
56.5
TO 60.0
|
0.6
to 2.0
|
-
|
0.30
Max
|
-
|
-
|
0.2
Max
|
Remn.
|
-
|
|
CuZn40Pb2
|
57
TO 59
|
1.5
to 2.5
|
-
|
0.40
Max |
-
|
-
|
0.7
Max
|
Remn.
|
-
|
|
|
SPECIAL
HIGH TENSILE BRASS FOR VALVES
|
GRADE
1 GENERAL
|
56.5
TO 60.0
|
0.75
to 1.75
|
-
|
0.30
Max |
-
|
0.4
to 1.1
|
0.75
Max incl.Fe
|
Remn.
|
-
|
|
GRADE
II I.O.C.
|
56.5
TO 60.0
|
1.0
to 1.5
|
-
|
0.30
Max
|
-
|
0.2
to 0.5
|
0.70
Max incl.Fe
|
Remn.
|
-
|
|
|
RIVETING
BRASS RODS LEAD FREE
|
BS
: 2874/86 CZ109
EQUV.: IS 4170/67 CuZn 40 |
59
TO 62
|
-
|
-
|
-
|
-
|
-
|
0.30
Max
|
Remn.
|
-
|
|
IS
: 4413/81
CuZn37 EQUV.: BS/2873/86 CZ 108 |
62-6
5
|
0.30
Max
|
-
|
0.10
Max
|
-
|
-
|
0.60
Max
|
Remn.
|
-
|
|
|
HIGH
TENSILE BRASS RODS
|
BS:
2874/86 CZ114
EQUV.: BS 250 |
56.5
TO 58.5
|
0.5
to 1.5
|
0.2
to 0.8
|
0.3
to 1.0
|
1.5
Max
|
0.5
to 2.0
|
0.5
Max
|
Remn.
|
-
|
|
BS:
2874/86 CZ115
EQUV.: BS 1001 |
56.0
TO 58.5
|
0.5
to 1.5
|
0.62
to 1.1
|
0.25
to 1.2
|
0.2
Max
|
0.3
to 2.0
|
0.5
Max
|
Remn.
|
-
|
|
|
HIGH
TENSILE BRASS RODS I
|
IS:320/80
|
56.0
TO 60.0
|
0.2
to 1.5
|
0.2
to 1.0
|
0.2
to 1.25
|
0.2
Max
|
0.25
to 2.0
|
0.5
Max
|
Remn.
|
-
|
|
HIGH
TENSILE BRASS RODS II
|
IS:320/80
|
556.0
TO 61.0
|
0.5
to 1.5
|
1.0
Max
|
0.2
to 1.5
|
0.3
to 2.0
|
0.5
to 2.0
|
0.5
Max
|
Remn.
|
-
|
|
RIVETING
BRASS RODS LEADED
|
IS:2704/83
CuZn35Pb1 |
62.0
TO 65.0
|
0.75
to 1.5
|
-
|
0.1
Max
|
-
|
-
|
0.5
Max
|
Remn.
|
-
|
|
IS:2704/83
CuZn35 |
63.0
TO 68.0
|
0.02
Max
|
-
|
0.1
Max
|
-
|
-
|
0.3
Max
|
Remn.
|
-
|
|
|
NAVAL
BRASS ROD GRADE I
|
IS:291/77
GR.I
EQUV.: BS2874 CZ 112 |
61.0
TO 64.0
|
0.20
Max
|
1.0
to 1.5
|
0.1
Max
|
-
|
-
|
0.2
Max
|
Remn.
|
-
|
|
NAVAL
BRASS ROD GRADE II
|
IS:291/77
GR.II
|
59.0
TO 62.0
|
0.5
to 1.0
|
0.5
to 1.0
|
-
|
-
|
-
|
0.2Max
|
Remn.
|
-
|
|
NICKEL
SILVER ALLOY RODS
|
BS:2874/86
NS 101
|
44.0
TO 47.0
|
1.0
to 2.5
|
-
|
0.4
Max
|
-
|
0.2
to 0.5
|
0.3
Max
|
Remn.
|
9.0
to 11.0
|
|
COPPER
ROD FOR GENERTAL ENGG PURPOSE
|
BS:2874/86
CC 101 |
REMAINDER
|
-
|
-
|
-
|
-
|
-
|
0.36
to 1.4 (chromium)
|
-
|
-
|
